15H Recording 3G 4G S5L Body Worn Video Camera

Ask Lasest Price
Brand Name :	Anyuan
Model Number :	AY-MB1228-4G
Certification :	CE, FCC
Price :	Negotiation
Payment Terms :	T/T, Western Union, MoneyGram, Paypal
Supply Ability :	50K per month
Delivery Time :	5-7 days

Add to Cart

Product Details
Company Profile

15H Recording 3G 4G S5L Body Worn Video Camera

Body Worn Video Camera Face Recognition 3G 4G LTE Wireless ONVIF Wearable Police Body Worn Camera

Our body worn cameras are widely used in police force, security Patrol, fire protection, drug, railway, court, customs, electric power, procuratorate, etc.

AY-MB1228 series

Key Specifications/Special Features:

Chipset: S5L Chipset
Video encoding: H.265
Long-time recording: up to 15 hours with one 3500mAh battery 1080p high-definition video recording, support 1512p max.
Battery protect technology
Startup time: <6 seconds (from power on to recording)
Other feature: waterproof IP68
With PTT function/Facial Recognition option
Languages: English/Chinese
OEM ODM projects are available
32/64/128/256GB built-in TF card for option(basic configuration is 32GB TF card)
(optional)Wi-Fi/3G/4G/GPS supported support

Model		AY-MB1228
OS	Chipset	Ambarella S5L
	OS	Linux 4.9.110
	Booting time	< 6 Seconds (From power on to recording)
	Language	English/Chinese
Video	Video input	OS05A10
	Video output	2 inch Full HD LCD screen
	Recording Resolution	2560x1440,1920x1080,1280x720
	Frame rate	1440p30,1080p60,1080p30,720p60,720p30
	Compression	H.264(MP/HP Level 5.1)/H.265(MP Level 5.0)
Audio	Audio input	1x MIC input, optional external intercom audio input
	External audio interface	2.5mm jack for headphone, microphone and PTT
	Compression	PCM format (AAC optional)
Video process	Video resolution	2560x1440, 1920x1080, 1280x720
	Photograph	1920x1080 ～ 8640x4752
	Snap	Support snapping during recording(photo resolution same as recording video)
	Storage	Built in 16GB TF card(optional for 32～256GB)
Light	IR	Up to 10 Meters at 0 lux with Visible shape image
	Flash light	help for view in night
	Laser	lock image center or pointing
Lens	HOV	>120°
Alarm	SOS	SOS key press will be notificated on the platform (only for 4G/3G device)
COM port	USB	1x USB,for charging, communication with PC, connect external HD camera
	3G/4G	built in 3G/4G module(FDD-LTE/WCDMA/GPRS) (only for 4G/3G device)
	wifi	Optional,support WIFI Client and AP mode
GPS	GPS	GPS/GLONASS(optional),location and speed can be used in local record and remote view, excellent signal quality with cold start <25 seconds
Firmware	Face Recogntion	With face recognition, huge local blacklist or cloud recognition
	Remote image function	Support online playback and downloading remotely (only for 4G/3G device)
	Playback speed	Support from 1 to 128
	Pre/post- recording	Maximum 20s pre-recording and post-recording
	Dewarp	Support dewarp before encoding(>120 degree), support maximum 8X digital zoom
	Record encryption	Support Record encryption, encrypted video can be only played in special player
	Log	Record key operation, setting change, events, alarms and other information
Working condition	Temperature	-30--60℃
Working condition	Humidity	40%～80%
Time		synchronize date and time with GPS, internet, PC
Dual video stream		2 Independent Video Streams for Local Record and Remote View
Battery capacity		Option 1: 3500mAh for 1080p30 continuous recording upto 14h, for continuous 4G remote view up to 7.5h, Full charged within 3h
Battery capacity		Option 2: 4200mAh for 1080p30 continuous recording upto 15h,for continuous 4G remote view up to 9h, Full charged within 3.5h;
Waterproof		IP68
Size		83.254.829.8mm
Wight		145g(without clip)

Body Worn Video Camera are mostly used:

Fire Protection

Play a big role in the working process of firefighters, even in special circumstances, can all-weather recording site, remote make timely solution to the accident, improve the processing efficiency. At the same time support a key remote alarm function, the console and the surrounding personnel make timely feedback, reduce the accident delay.

●The key to improve the efficiency of alarm function.

●The remote video monitoring, timely processing of the issue

● long standby time, can work polyphonic video recording

● The infrared night vision function, timely recording of the scene

Administrative Enforcement

Administrative law enforcement is the basis of service law enforcement recorder application, application of rules based on the original instrument of law enforcement, law enforcement personnel in law enforcement is an important equipment in the administration, with audio and video recording function, remote connection function and a key alarm function, increase the efficiency of law enforcement, law enforcement recorder collection process ensure fairness, openness, the legal effect of audio and video evidence collection.

● avoid all kinds of illegal acts appear
● record the scene of the accident, convenient evidence
● law enforcement control, avoid disputes
● improve the efficiency of law enforcement, to ensure the safety of the masses

Security Patrol

Security patrol recorder is used in law enforcement relative directivity, which plays a role of security personnel in a certain range, the law enforcement recorder of personnel and goods control, while dealing with complex situations can also contact personnel timely treatment, greatly improve the efficiency of law enforcement patrols during the recording scene all day long, ensure all day long safety.
● The entry of personnel monitoring, strengthen personnel and goods management
● The abnormal situation timely prevention
● promptly contact the relevant personnel, improve the processing speed of the accident

Court

Can recording the execution scene, the judges are for the case of execution, they will be through the law enforcement recorder and every act and every move command terminal, transmission command center. For possible emergencies in the process of implementation, timely take the seizure, freezing, fines, detention and other compulsory measures.

● The whole record of the hearing.

● It can be shifted to the case, the reduction process of the accident

● Under field condition to take relevant measures
