Function | Performance |
System | Language | English / Chinese |
Operation Interface | Graphical User Interface (OSD menu) |
Password Security | 2 Levels: Administrator or User |
Video | Video Input | Supports 4 channels CIF/HD1/D1/960H/720P AHD camera Video input |
Supports 2-CH 720P AHD + 2-CH 960H analog mixing Video input |
Supports 1-CH 720P/1080P IPC + 4-CH 960H/D1/CIF Video input |
Note: 4 channels 720P AHD or 1-CH 720P/1080P IPC + 4-CH 960H Video
input will require high speed SD card ( > 80Mb/S, Class 10 or
higher) |
Video Output | 2 Channels (Front Panel 3.5mm Jack, Rear Panel on 24 pin I/O Port ) |
Video Display | Single picture, 1~5 pictures |
Signal System | PAL / NTSC ( PAL@100 frame 720P/sec; NTSC@120 frame 720P/sec ) |
Image Compression | H.264 Main profile |
Audio | Audio Input | 4 Channels |
Audio Output | 2 Channels (Front Panel 3.5mm Jack, Rear Panel on 24 pin I/O Port ) |
Recording Format | Synchronized A/V recording |
Recording & Storage | Image Resolution | CIF / HD1 / D1 / 960H / 720P optional |
Video Coding | ISO14496-10 Industry Standard |
Video Bit Rate | CIF: 1536Kbps ~ 128Kbps, |
HD1/D1: 2048Kbps ~ 400Kbps, |
960H: 2048Kbps ~ 400Kbps, |
720P:4096Kbps ~ 400Kbps |
Select from 8 Levels of Video Image Quality ranging from 1
(Highest) to 8 (Lowest) |
Audio Bit Rate | 40Kbps |
Storage | 2 SD Card Slots, Up to 128GB each, Class 10 or higher |
Alarm | Alarm Input | 8 Channels, Select trigger for either less than 1VDC or greater
than 5VDC |
Alarm Output | 1 Channel, 12V output |
Communication Ports | RS485 | 1 Port for communication or data usage |
RS232 | 2 Port for communication or data usage |
RJ45 Network | 1 Port of RJ45. For connection to an IP camera with maximun of
1080P |
Wireless Communication* | 3G* | 3G (HSUPA / HSDPA / WCDMA / EVDO / TD-SCDMA) optional internal
module |
4G* | (TDD-LTE / FDD-LTE) optional internal module to match local
cellular carrier |
Wi-Fi* | Internal Wi-Fi 802.11b/g/n (2.4 / 5.8 Ghz) option |
GPS* | Int'l Standard GPS* | Internal GPS module. Real-time geographic coordinates, speed
information |
G-Sensor | Internal G-Sensor | Supports 3 Axis Motion Detection with user set ranges for X, Y and
Z coordinates |
Software | PC Playback | A/V, GPS, Mapview, Speed, G-Sensor, etc. files available for
playback on PC. Limited playback is also available on MDVR |
IVMS | Wireless (requires Wi-Fi or cellular Option) real-time A/V
monitoring, GPS, alarms, etc. |
Software Upgrade | Local or Remotely | Upgrade through SD card or remotely via IVMS platform |
Voltage Input | +8～+36V | 8～36VDC Please check operational voltage of vehicle prior to the
installation of the MDVR and its accessories to prevent possible
damage. |
Voltage Output | 12V | 12V(+/-0.2V),Max 3A |
ACC Detection | ≤4V | Power-off |
≥6V | Power-on |
Video Input Resistance | 75Ω | 75Ω |
Video Output Voltage | 2Vp-p | 2VP-P CVBS output analog signal, screen input requires 75Ω
resistance |
I / O Port | <1V | Low voltage trigger |
>5V | High voltage trigger |
Operational Temperature | -25℃ ~ 75℃ | Install in well ventilated area, protected from moisture, heat,
dust and vibration |
Dimensions | 170x142x50mm | Including Security Cover 170x187x50mm |
